Heating Dry Bath

dry bath DH-10
dry bath DH-10

DH-10 dry bath is a constant temperature metal bath device controlled by a microcomputer, with high temperature control accuracy and good parallelism of sample preparation. It can replace the traditional water bath device. It can be widely used in the cultivation, preservation and reaction of various samples, and the application industry covers medicine, chemical industry, food. Safety, quality inspection, environment, etc.

Contact
Online Consult
  • Description
  • Specifications
  • Paper
  • Video



DH-10 dry bath is a constant temperature metal bath device controlled by a microcomputer, with high temperature control accuracy and good parallelism of sample preparation. It can replace the traditional water bath device. It can be widely used in the cultivation, preservation and reaction of various samples, and the application industry covers medicine, chemical industry, food. Safety, quality inspection, environment, etc.





1. LED display, clean and simple interface.

2. The instrument has fast heating speed, uniform heating, accurate temperature control, high stability, low energy consumption and no noise.

3. Built-in temperature deviation calibration function, automatic fault detection and buzzer alarm function.

4. Built-in over-temperature protection device, which is safer and more reliable to use and prolongs the service life of the machine.

5. The product design is compact and tight, occupying a small range of space, bringing more freedom and convenience.

6. A variety of module options, replacement, easy to clean and sterilize various test tubes.



Model
DH-10
Temperature Control Range
Room temperature+5℃ ~ 100℃
Heating time
≤ 30 minutes (from 20°C to 100°C)
Temperature stability (at @40~100℃)
≤±0.5℃
Module maximum temperature difference@40℃
0.3℃
Module temperature uniformity
≤±0.5℃
Temperature display accuracy
0.1℃
Longest Timing
99h59min
High temperature
100℃
Maximum power
150W
Product size
260x220x95mm
Product weight
≤2.1kg



Module model selection:
Model
Pore size and number of tubesMax temperatureMaximum number of revolutions
DW3096×0.2mlstandard board100℃1500rpm
DW3154×0.5mlCentrifuge tube100℃1500rpm
DW3235×1.5mlCentrifuge tube100℃1500rpm
DW3335×2.0mlCentrifuge tube100℃1500rpm
DW3415×0.5ml+20×1.5mlCentrifuge tube100℃1500rpm
DW3524×diameter≤φ12mmTest tube100℃1200rpm
DW3632×0.2ml+25×1.5mlCentrifuge tube100℃1500rpm
DW3732×0.2ml+10×0.5ml+15×1.5mlCentrifuge tube100℃1500rpm
DW38103×67×30 (square slot module)100℃1500rpm
DW3996×0.2mlMicroplate ( Flat bottom)100℃1500rpm
DW4024x5ml Centrifuge tube100℃1200rpm
DW4112x15ml100℃600rpm
DW42

6x50ml

100℃600rpm
DW43

15x10ml

100℃600rpm
Other non-standard customizationCan be customized//



host1 set
module1 piece
power cable1 root
Special screwdriver (for removing the module)1 set
user's manual1 part
certificate1 part
Warranty Card1 part
