Heating Dry Bath
Heating Dry Bath DH200-4 high-temperature dry thermostat controlled by a microcomputer uses high-purity aluminum material as a heat-conducting medium to replace the traditional water bath device. It has the characteristics of convenient use, large temperature control range and high precision. Reaction, DNA amplification and pre-denaturation of electrophoresis, serum coagulation, etc. Using two-level redundant hardware circuit design, with unique intelligent software algorithm, high temperature control accuracy, stable and reliable operation.
- Description
- Specifications
- Paper
- Video
Heating Dry Bath DH200-4 high-temperature dry thermostat controlled by a microcomputer uses high-purity aluminum material as a heat-conducting medium to replace the traditional water bath device. It has the characteristics of convenient use, large temperature control range and high precision. Reaction, DNA amplification and pre-denaturation of electrophoresis, serum coagulation, etc. Using two-level redundant hardware circuit design, with unique intelligent software algorithm, high temperature control accuracy, stable and reliable operation.
◆ Instant temperature display, time decrement display;
◆ Automatic fault detection and buzzer alarm function;
◆ With temperature deviation calibration function;
◆ Convenient module replacement for easy cleaning and disinfection;
◆ Built-in over-temperature protection device;
◆ Two-level redundant hardware circuit design, more reliable use;
Model | DH200-4 |
Temperature control range | Room temperature+5℃~120℃ |
Temperature control accuracy | ±0.5℃(@40℃); ±1℃(@120℃) |
Heating time | ≤20min (25℃~120℃) |
temperature uniformity | ±0.5℃ |
Display accuracy | 0.1℃ |
Number of modules | 2~4 |
Timing range | 1-99h59min/∞ |
voltage | AC 220V |
Maximum power | 600W |
Product size | 360*220*100mm |
Product weight | 8.0kg |
Module model selection | |||
Model | Tube diameter | Number of test tubes | Module size |
DT01 | 6mm | 42 | 95.5×76.5×50 |
DT02 | 7mm | 42 | 95.5×76.5×50 |
DT03 | 10mm | 20 | 95.5×76.5×50 |
DT04 | 12mm | 20 | 95.5×76.5×50 |
DT05 | 13mm | 20 | 95.5×76.5×50 |
DT06 | 15mm | 12 | 95.5×76.5×50 |
DT07 | 16mm | 12 | 95.5×76.5×50 |
DT08 | 19mm | 12 | 95.5×76.5×50 |
DT09 | 20mm | 6 | 95.5×76.5×50 |
DT10 | 26mm | 6 | 95.5×76.5×50 |
DT11 | 28mm | 4 | 95.5×76.5×50 |
DT12 | 40mm | 2 | 95.5×76.5×50 |
DT13 | 0.5ml | 40 | 95.5×76.5×50 |
DT14 | 1.5ml | 24 | 95.5×76.5×50 |
DT15 | 2.0ml | 24 | 95.5×76.5×50 |
DT16 | 0.2ml | 48 | 95.5×76.5×50 |
DT17 | 0.2ml | 96 | 78×114×26 |
DT18 | flat | 96-well microtiter plate (plate) | 81×123×19 |
DT19 | Can be customized | Can be customized | Can be customized |
host | 1 set |
module | 2-4 piece |
power cable | 1 root |
Special screwdriver (for removing the module) | 1 set |
user's manual | 1 part |
certificate | 1 part |
Warranty Card | 1 part |
